Single Conical Spring Mechanical seal

Type SRD is factory assembled & dynamically tested seal for steel, glass lined and SS mixers, agitator & vessels. This is a multiple spring externally mounted, reverse balanced seal with O-ring as secondary sealing member. Various elastomers can be offered for wide service application. These seals are basically used on top entry agitators as dry running seals. When food products or pharmaceutical products are agitated in agitator, mixing of any other liquid will contaminate the product & affect its quality, hence these dry running seals are used. These seals don’t require any external media for lubricating the faces, that is why they are known as dry running seals.

Face

Carbon, Ceramic, Silicon carbide

Hardware

SS 316, SS 304, Hastelloy-C, Hastelloy-B, Monel, Alloy-20

Secondary seal

Elestomer, PTFE, FEP, TTV

Application

Food Products, Pharmaceutical Products

Shaft diameter

15mm to 150mm

Pressure

Vacuum -8 Bar (Max)

Temperature

. Amb to 200 deg C
