Reversed Balanced Mechanical seal

The Reversed Balanced Mechanical Seal (Type SRD) is a dry-running, externally mounted seal ideal for mixers, agitators, and vessels in food and pharmaceutical processing. Designed to prevent product contamination, it offers reliable sealing without external lubrication and is compatible with various face and elastomer materials for versatile applications.

Materials
Seal Faces: Carbon, Ceramic, Silicon carbide
Hardware: SS 316, SS 304, Hastelloy-C, Hastelloy-B, Monel, Alloy-20
Secondary Seals: Elastomer, PTFE, FEP, TTV

Application
Food products processing
Pharmaceutical manufacturing

Shaft Diameter Range: 15 mm to 150 mm
Pressure: Vacuum to 8 bar (max)
Temperature: Ambient to 200°C
